Power distribution device. Allow to reduce harness volume or add power outputs to your actual PDM
Documentation on request
This power box drive up to six "high side" outputs with 10A nominal current each and 30A nominal other all.
These values can be higher depending of the duty cycle during use.
Caractéristiques:
- Size :48x46x30mm
- Weight:46g
- Connector : MX120G
- Wires: max section 1mm2
- Enclosure:over molded
- Protection:IP67
- Temp.:-20ºC / +80ºC
- Configuration: via PC (Windows)
- Interface USB/CAN : LAWICEL (also version Skynam) ou PEAK system
- Protections:
* Overload
* Short circuit
* Over/under voltage
- Drived through CAN or in "stand alone" using CAN information.
Sold with or without connector (the connector kit include some terminales)
USB/CAN not sold. Must be ordered directly to supplier.
Also available :
- High Power version with 2x80A and 4x40A ouputs
- Dual version with 2x75A, 4x25A and 6x15A (and 4 analog inputs)
- LED driver 6 output up to 1,8A each drive through CAN (slave mode).
